Furman F1500-UPS E - UPS pentru Rack 1500VA, Power Conditioner

Descriere

Furman F1500-UPS E este o sursa de alimentare neintreruptibila (UPS) - baterie de rezerva / putere. Interfete 2RU, AVR, RS-232 si USB. compatibil BlueBOLT. Bateria de backup F1500-UPS E proiectata exclusiv pentru profesionistii din domeniul audio / video si pentru pasionatii de home theater.

Furman F1500-UPS E - UPS 1500VA, mentine datele critice si permite oprirea corecta a echipamentului.

Avand in vedere natura tehnologiei de rezerva a acumulatorilor, componentele audio si video de inalta tensiune, cum ar fi amplificatoarele de putere, subwooferele cu alimentare si afisajele de inalta putere, nu sunt recomandate pentru utilizarea cu F1500-UPS E. Nu numai ca aceste componente vor scurge prea mult bateria , impedanta de linie va fi ridicata datorita invertorului F1500-UPS E (sau a oricarui altul) AVR si AC to DC, care poate induce compresia curenta si poate diminua semnificativ performanta cu echipamentele A / V cu curent ridicat. Urmatoarele componente sunt ideale pentru utilizarea cu F1500-UPS E:
-DAWs
-Satellite Receivers
-Cable Boxes
-Digital Video Recorders
-Media Servers
-External Hard Drives
-Lamp Based Video Displays
-Control Systems

FUNCTII:

• Surge Protection
  • Furman’s exclusive SMP technology provides the highest level of surge & spike protection available.
• Noise Filtration
  • LiFT offers AC power filtering to ensure clean power for unequaled audio & video clarity.
• Voltage Protection
  • Advanced EVS circuitry detects dangerous voltage irregularities and safely powers down itself and connected equipment in unsafe conditions.
• Diagnostic Indicators
  • Digital indicators provide information on power quality and operational status of unit.
• Battery Backup
  • 1500VA true sine wave battery backup protects your data in a power failure allowing the opportunity to save your applications, programs, and shut-down the system gracefully .
• Critical Load Management
  • Critical Load Management prioritizes the allocation of temporary power to connected equipment.
• Infrared Control
  • Dual Learning IR Blasters allow safe shutdown of remote components.
• BlueBOLT® Compatible
  • BlueBOLT® TCP/IP interface provides remote control to reboot components, power equipment on or off, and monitor power quality from anywhere in the world.
• Custom Programming
  • Custom programming provides control of unit via RS-232 card (included) or optional TCP/IP interface card (sold separately)
• 12 AMP Rating
  • 12 Amp rating featuring a circuit breaker for added protection.
• Eight Total Outlets
  • Eight total outlets rear outlets in isolated banks (Critical and Non-Critical loads).
• Standard Voltage Regulation
  • Standard level automatic voltage regulation (AVR) delivers a stable 120 volts of AC power to protect equipment from problems caused by AC line voltage irregularities.
• Power Control Software
  • Easy to use power control software assists you in maximizing the performance of your UPS.
• Optional Battery Extension Pack
  • External battery packs (sold separately) are available and may be daisy-chained to the F1500-UPS increase battery capacity.

Specificatii Complete:

General

• Family: F-Battery
• Line Voltage: 120 (Volts)
• Number of Outlets: 8
• Number of Isolated Banks: 2
• Outlet Descriptions: All 8 outlets surge protected, linearly filtered, and backed up
• Rack Mountable: Yes
• Rack Ears Included: Yes
• Front Panel Meter(s)LCD Displays status and menu navigation items
• Front Media Light(s): No
• Control: Remote control through RS-232 interface card or via internet with BlueBOLT-CV1 card (sold separately)
• AC Power Cord: Heavy duty captive power cord
• Dimensions: 17" W (19" w/ rack ears) x 19.2" D x 3.5" H (4" tall with feet installed)
• Weight: 72 lbs.

Battery Backup

• Input Frequency57 - 63 Hz
• Regulation Capture Range:
  96 - 135V (Sensitive Mode)
  93 - 142V (Standard Mode)
• Output Frequency:
  60 Hz ± 1%
• UPS Output Capacity:
  1500VA, 900W @ 0.6pf
• Regulation Output Range:
  120V ± 5% (Sensitive Mode)
  120V ± 10% (Standard Mode)
• UPS Backup Time (Full Load): 12 minutes
• UPS Backup Time (Half Load): 32 minutes
• Transfer Time< 4ms

AC Protection

• AC Protection Technology:
  Non-sacrificial SMP (Series Multi-Stage Protection)
• Over-Voltage Shutoff:
  150V ± 5V (fast rise)
  140 ± 5V (slow rise)
• Maximum Current Rating: 12 (Amps)

Filtration

• Filtration Technology:
  Linear Filtering Technology (LiFT)
• Filtration Rating:
  10 dB @ 10kHz
  40 dB @ 100 kHz
  50 dB @ 500kHz
